cara Print Clean pro is an automated 3DP cleaning system that agitates isopropanol in a contained volume to clean excess, uncured resin from 3D-printed parts.

cara Print Clean pro is our answer to the critical step between printing and curing dental appliances. One touch operation should not end at the printing phase: automate your post-processing with thorough, no-mess cleaning at the push of a button while protecting yourself from too much exposure to isopropanol.

The new pro version has an even larger chamber to work seamlessly with the new cara Print 4.0 pro 3D printer.

3D Print Workflow 3

Control interface on cara Print Clean

Simple controls

The comprehensive cara Print System

cara Print System

cara Print 4.0 3D printer for dental applications

3D Print Workflow 5

See it from every angle! Click on the image to see a 360° view of cara Print Clean pro.

cara Print Clean Pro

3D printer

cara Print 4.0 pro

cara Print 4.0 pro is a 3D printer that easily meets the accuracy requirements for all polymer-based dental appliances. Perfectly fitting restorations, printed in less than 1 hour in most cases.

Go to product details
HiLite power 3D

Polymerization for 3D printing

Designed specifically to meet the needs of 3D printing, the easy-to-use HiLite power 3D provides enough space for restorations and offers pre-set programs with the option to create additional shortcuts for up to ten user-defined programs.

Go to product details
cara Service

So that everything works.

Service is important, yet often underestimated. Our dental experts are always available for support before, during and after your purchase. Kulzer offers comprehensive support to ensure dental labs are always fully operational.

Contact us
cara LED cure

Post-curing unit

cara Print LEDcure offers the flexibility to set the time, temperature and LED intensity to ensure optimal illumination conditions for all opaque & transparent 3D print materials.

Go To Product Details


Technical details at a glance
Dimensions / weight	W 19.9 x D 26.3 x H 47.4 cm / 3.7 kg (empty)
Cleaning agent	Isopropyl alcohol (isopropanol), handle with care.
Min./ max. filling	Min. 1.3, Max. 2.0 liters, depending on height of 3D printed objects
Cleaning technique	Magnetic stirrer (speed: slow, medium & fast) and circuit pump
Cleaning time	Cleaning time between 1 or 10 minutes possible; actual time needed depends on material and part geometry.
Max. size of printed parts	W 12.4 x D 7.0 x H 13.0 cm
Recommended build table hanger	Object height under 70 mm: use extended build table hanger Object height over 70 mm: use short build table hanger
Scope of supply	Lid Short and extended build table hanger Inner container & plug Outer container cara Print Clean Base Power supply Part tray 2 magnetic stir bars 3 extra foam gaskets Extra container plug
Power supply	Mains: 100 – 240 VAC, 50/60 Hz (grounded)
Warranty	1 year

Overview

cara Print Clean pro is an automated 3DP cleaning system that agitates isopropanol in a contained volume to clean excess, uncured resin from 3D-printed parts.

cara Print Clean pro is our answer to the critical step between printing and curing dental appliances. One touch operation should not end at the printing phase: automate your post-processing with thorough, no-mess cleaning at the push of a button while protecting yourself from too much exposure to isopropanol.

The new pro version has an even larger chamber to work seamlessly with the new cara Print 4.0 pro 3D printer.

Benefits

Good to know

3D Print Workflow 3

Control interface on cara Print Clean

Simple controls

The comprehensive cara Print System

cara Print System

cara Print 4.0 3D printer for dental applications

3D Print Workflow 5

Applications

See it from every angle! Click on the image to see a 360° view of cara Print Clean pro.

cara Print Clean Pro

3D printer

cara Print 4.0 pro

cara Print 4.0 pro is a 3D printer that easily meets the accuracy requirements for all polymer-based dental appliances. Perfectly fitting restorations, printed in less than 1 hour in most cases.

Go to product details
HiLite power 3D

Polymerization for 3D printing

Designed specifically to meet the needs of 3D printing, the easy-to-use HiLite power 3D provides enough space for restorations and offers pre-set programs with the option to create additional shortcuts for up to ten user-defined programs.

Go to product details
cara Service

So that everything works.

Service is important, yet often underestimated. Our dental experts are always available for support before, during and after your purchase. Kulzer offers comprehensive support to ensure dental labs are always fully operational.

Contact us
cara LED cure

Post-curing unit

cara Print LEDcure offers the flexibility to set the time, temperature and LED intensity to ensure optimal illumination conditions for all opaque & transparent 3D print materials.

Go To Product Details

Specifications


Technical details at a glance
Dimensions / weight	W 19.9 x D 26.3 x H 47.4 cm / 3.7 kg (empty)
Cleaning agent	Isopropyl alcohol (isopropanol), handle with care.
Min./ max. filling	Min. 1.3, Max. 2.0 liters, depending on height of 3D printed objects
Cleaning technique	Magnetic stirrer (speed: slow, medium & fast) and circuit pump
Cleaning time	Cleaning time between 1 or 10 minutes possible; actual time needed depends on material and part geometry.
Max. size of printed parts	W 12.4 x D 7.0 x H 13.0 cm
Recommended build table hanger	Object height under 70 mm: use extended build table hanger Object height over 70 mm: use short build table hanger
Scope of supply	Lid Short and extended build table hanger Inner container & plug Outer container cara Print Clean Base Power supply Part tray 2 magnetic stir bars 3 extra foam gaskets Extra container plug
Power supply	Mains: 100 – 240 VAC, 50/60 Hz (grounded)
Warranty	1 year

Downloads

Katalogpreise

Auf Lager

Nur noch %1 verfügbar

Freshly printed restorations are usually cleaned by hand – unless you have Kulzer’s cleaning device: cara Print Clean pro

Dima Print Stone Beige Smart Weiter

Dima Print Stone Beige Smart

cara Print Clean pro Vorherige

cara Print Clean pro

Filter zurücksetzen

	Name	Typ	Listenpreis	Ihr Preis	Menge
	cara Print CleanUp Ref66100119	Typ CleanUp	Listenpreis 175,00 €	Ihr Preis 0.0000 Bitte loggen Sie sich ein, um Ihre individuellen Preise und Rabatte zu sehen Einloggen	Menge
